Integration Partner Modules-Control4

Device Driver(s) for various motor and lighting (LED) control products are currently available from Vantage.

Simply login to Design Center V 4.1 or later for the latest functionality and lastest compatible drivers (old drivers with motor and led control all built into the same driver used with Design Center V 3.8 to 4.0 had an issue with the Core Release). New drivers are now broken out with a separate driver for motor control and a separate driver for LED control. For installations where a common e-Node will be used to support LED and Motor controllers, simply load two drivers and give each a separate set of Telnet usernames and passwords (since the e-Node has 4 separate IP sockets--this works perfectly). The latest driver set customized for V 4.1.1 are masterpieces thanks to some great work our joint team of engineers.

Note: If any sample projects are provided below, they are in .zip format. Download the file, unzip and open as a new project..

Model	Interface	Functions	Sample Screens/Downloads

ILC-x00 LED Controller	e-Node (IP)	Controls device(s) using IP Telnet communication with and w.o authentication Controls lighting state (ON/OFF) Controls lighting presets (P1-P24) Controls lighting effects (Effect #1,#3, #4) Controls Color Temperature from 1700K to 7000K Support Vantage's Architectural and Residential App features Controls custom commands such as Circadian "show" Controls multiple zone, group, and node (Z.G.N) addresses Controls setup, dissolve rate and sequence rate Supports basically every feature of LED controllers available with permitted proxies of Vantage-this is a big deal! Enables bi-directional feedback for RGB, RGBW, HSB and Color Tempertures	Quick Start Guide (2021) Integration Notes Module Download Sample Project
ILC-x00 LED Controller	IBT-100 (RS-232c)	Controls device(s) using RS-232-C communication Controls device(s) using IP Telnet communication with and w.o authentication Controls lighting state (ON/OFF) Controls lighting presets (P1-P24) Controls lighting effects (Effect #1,#3, #4) Controls Color Temperature from 1700K to 7000K Support Vantage's Architectural and Residential App features Controls custom commands such as Circadian "show" Controls multiple zone, group, and node (Z.G.N) addresses Controls setup, dissolve rate and sequence rate Supports basically every feature of LED controllers available with permitted proxies of Vantage-this is a big deal! Enables bi-directional feedback for RGB, RGBW, HSB and Color Tempertures	Quick Start Guide (2021) Integration Notes Module Download Sample Project
IMC-100 Single Motor Controller	e-Node (IP)	Controls motor direction (up,down, and stop) Controls intermediate presets (IMC-100T) Controls multiple zone, group, and node (Z.G.N) addresses	Quick Start Guide (2021) Integration Notes Module Download Sample Project
IMC-100 Single Motor Controller	IBT-100 (RS-232c)	Controls motor direction (up,down, and stop) Controls intermediate presets (IMC-100T and CVM) Controls multiple zone, group, and node (Z.G.N) addresses	Quick Start Guide (2021) Integration Notes Module Download Sample Project
CVM/IMC-300 MKII Triple Motor Controller	e-Node (IP)	Controls motor direction (up,down, and stop) Controls intermediate presets (CVM) Controls multiple zone, group, and node (Z.G.N) addresses Enables bi-directional feedback for motor location (MKII)	Quick Start Guide (2021) Integration Notes Module Download Sample Project
IMC-300 (BRIC I) Triple Motor Controller	Built-in Serial	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors *Enables bi-directional feedback for motor location (MKII)	Integration Notes Module Download Sample Project
IMC-300 (BRIC I) Triple Motor Controller	External IP (e-Node)	Controls two separate motors digitally with up,down, and stop controls Controls third motor (traditionally a door motor) with up and down controls Controls multiple zone, group, and node (Z.G.N) addresses Controls multiple BRIC addresses (units 1-4) Controls up top 8 presets of multiple motors Enables bi-directional feedback for motor location (MKII)	Integration Notes Module Download Sample Project
