Device Driver(s) for various lighting (LED) control products and motor control products are currently available from Crestron. .
For lighting projects, simply launch your Crestron SIMPL Windows application and open our demo MC3 project (.smw) and review the functionality supported within our devices. Then launch your Crestron VisionTools Pro-e application to customize your user interface using our .vtp demo file for guidance. The referenced download below makes it very easy to integrate a Crestron control system with Converging Systems' lighting projects. Excellent bi-directional feedback is now available with our LED lighting control products, including color temperature and RGBW functionality. Contact Crestron for more information.
The Sample Project for which a weblink is specified below, has an updated driver updated by Converging Systems which integrates both motor LED lighting control into a single driver. It is exactly the same driver as written by Crestron except the motor control operators have been entered as "Serial I/O commands." Crestron has separate motor control and lighting control drivers, but this harmonized driver (contained within the Sample Project) is very useful where motor and lighting control is desired within the same driver.
Note: If any sample projects are provided below, they are in .zip format. Download the file, unzip and open as a new project..
| Model |
Functions |
Sample Screens / Downloads |
IMC-100 (via IBT-100 serial interface)
Single Motor Controllers
|
Controls device(s) using RS-232-C communication.
Controls motor direction (up,down, and stop).
Controls intermediate presets (IMC-100T).
Controls multipe zone, group, and node (Z.G.N) addresses.
Controls setup, browse, and help menus.
Enables bi-directional feedback for motor position (WIP)
|
Integration Notes
Module Download-V2.0
Sample Project
|
ILC-100 (via IBT-100 serial interface)
LED Lighting Controller
|
Controls device(s) using RS-232-C communication.
Controls lighting state (ON/OFF).
Controls lighting presets (P1-P24).
Controls lighting effects (Effect #1,#2).
Controls multipe zone, group, and node (Z.G.N) addresses.
Controls setup, dissolve rate and sequence rate.
Enables bi-directional feedback for color state.
|
Integration Notes
Module Download-V2.0
Sample Project (large download)
|
IMC-100 (via eNode-Ethernet Adapter)
Single Motor Controllers
|
Controls device(s) using Telnet UDP communication over
Ethernet (Port 23).
Controls motor direction (up,down, and stop).
Controls intermediate presets.
Controls multipe zone, group, and node (Z.G.N) addresses.
Controls setup, browse, and help menus.
Enables bi-directional feedback for color state.
Enables bi-directional feedback for motor position (WIP)
|
Integration Notes
Module Download-V2.0--wip
Sample Project
|
ILC-100 (via eNode-Ethernet Adapter)
LED Lighting Controller
|
Controls device(s) using Telnet communication over Ethernet (Port 23).
Controls lighting state (ON/OFF).
Controls lighting presets (P1-P24).
Controls lighting effects (Effect #1, #2).
Controls multipe zone, group, and node (Z.G.N) addresses.
Controls setup, dissolve rate and sequence rate.
Enables bi-directional feedback for color state.
|
Integration Notes
Module Download-V2.0
Sample Project
|
|
BRIC (via built-in serial interface)
3-motor Master Controller System
|
Controls device using built-in RS-232-C communication.
Controls two separate motor digitally with up, down,and stop controls.
Controls third motor (traditionally a door motor) with up and down controls.
Controls multipe BRIC addresses (unit 1-4).
Controls up to 8 preset multi-motor presets.
|
Integration Notes
Module Download-V1.0
Sample Project
|
|
BRIC (via external e-Node interface)
3-motor Master Controller System
|
Controls device using built-in RS-232-C communication.
Controls two separate motor digitally with up, down,and stop controls.
Controls third motor (traditionally a door motor) with up and down controls.
Controls multipe BRIC addresses (unit 1-4).
Controls up to 8 preset multi-motor presets.
|
Integration Notes
Module Download-V1.0
Sample Project
|
|
