Device Driver(s) for various motor control and LED lighting control products have been created by Savant. Authorized Savant dealers may click on the "Module" links and enter their dealer passwords for the lastest available profiles. Some of these profiles may be available for download here. If you see the tab "Local Profiles," you may click on that link for a non-Savant released profile.
| Model |
Functions |
Integration Notes / Downloads |
IMC-100 (via IBT-100 serial interface)
Single Motor Controllers
|
Controls device(s) using RS-232-C communication.
Controls motor direction (UP, DOWN and STOP).
Controls intermediate presets (IMC-100T).
Controls multipe zone, group, and node (Z.G.N) addresses.
Enables store presets capability.
Supports Data Table programming through BluePrint.
|
Integration Notes - Long Form Workflow Programming
Integration Notes - Short form for Data Table Programming
 Video Training (for Workflow only)
Driver/Profile
Sample BluePrint Project
e-Node Project File
Local Hosted Profiles
BluePrint Icon File
|
ILC-100 (via IBT-100 serial interface)
LED Lighting Controller
|
Controls device(s) using RS-232-C communication.
Controls lighting state (ON/OFF).
Controls lighting presets (P1-P24).
Controls lighting effects (Effect #1).
Supports Presets 1-24 (and storing capability).
Controls multipe zone, group, and node (Z.G.N) addresses.
Controls setup, dissolve rate and sequence rate.
Controls Saturation, Hue, Fade, Color Temperature with Savant sliders.
Controls Red, Green,Blue and White(for ILC-400) with Savant sliders.
Controls Corelated Color Temperature (CCT) with discrete buttons (1800K to 7000K).
Provides excellent bi-directional feedback for lighting states--sliders respond.
Supports Savant Infoboxes for read-back of color setttings (HSB, or RGB).
Controls Corelated Color Temperature (CCT) with discrete buttons (1800K to 7000K).
Supports Data Table programming through BluePrint.
|
Integration Notes - Long Form Workflow Programming
Integration Notes - Short form for Data Table Programming
Video Training
Driver/Profile
Sample BluePrint Project
e-Node Project File
Local Hosted Profiles
BluePrint Icon File
|
IMC-100 (via eNode-Ethernet Adapter)
Single Motor Controllers
|
Controls device(s) using TELNET communication over Ethernet/Port 23 (with Login).
Controls motor direction (UP, DOWN and STOP).
Controls intermediate presets.
Controls multipe zone, group, and node (Z.G.N) addresses.
Enables store presets capability.
Supports Data Table programming through BluePrint.
|
Integration Notes - Long Form Workflow Programming
Integration Notes - Short form for Data Table Programming
Video Training
Driver/Profile
Sample BluePrint Project
e-Node Project File
Local Hosted Profiles
BluePrint Icon File
|
|
ILC-100 (via eNode Ethernet Adapter)
LED Lighting Controller
|
Controls device(s) using TELNET communication over Ethernet/Port 23 (with Login).
Controls lighting state (ON/OFF).
Controls lighting presets (P1-P24).
Controls lighting effects (Effect #1).
Supports Presets 1-24 (and storing capability).
Controls multipe zone, group, and node (Z.G.N) addresses.
Controls setup, dissolve rate and sequence rate.
Controls Saturation, Hue, Fade, Color Temperature with Savant sliders.
Controls Red, Green,Blue and White(for ILC-400) with Savant sliders.
Controls Corelated Color Temperature (CCT) with discrete buttons (1800K to 7000K).
Provides excellent bi-directional feedback for lighting states--sliders respond.
Supports Savant Infoboxes for read-back of color setttings (HSB, or RGB).
Controls Corelated Color Temperature (CCT) with discrete buttons (1800K to 7000K).
Supports Data Table programming through BluePrint.
|
Integration Notes - Long Form Workflow Programming
Integration Notes - Short form for Data Table Programming
Video Training
Driver/Profile
Sample BluePrint Project
e-Node Project File
Local Hosted Profiles
BluePrint Icon File
|
|
BRIC (via built-in serial interface)
Single (or dual) BRIC Controller System
|
Controls device using built-in RS-232-C port.
Utilizes Savant Built-in drivers.
Controls two separate motor digitally with up, down,and stop controls.
Controls third motor (traditionally a door motor) with up and down controls.
Controls multipe BRIC addresses (unit 1-4).
Controls up to 8 preset multi-motor presets.
|
Integration Notes - Long Form Workflow Programming
Integration Notes - Short form for Data Table Programming
Sample BluePrint Project
e-Node Project File
Local Hosted Profiles
|
|
BRIC (via e-Node Ethernet Adapter)
Single (or Dual) BRIC Controller System
|
Controls device using external e-Node device (routed through built-in serial port on BRIC with BRIC "Port" set to BRIC mode and jumpers set for BRIC communicaton on e-Node).
Utilizes Savant Built-in drivers.
Controls up to four separate motor digitally with up, down,and stop controls.
Controls door motor with up and down controls.
Utilizes TELNET communication (Port 23) with Login authentication.
Controls up to 24 preset multi-motor presets.
|
Integration Notes
Driver/Profile
Sample BluePrint Project
e-Node Project File
Local Hosted Profiles
|
